Shenzhen Lean Kiosk Systems Co., Ltd.

MEI Bill Validation Payment Kiosk User Friendly , Maintenance Free Machine

Product Details:
Place of Origin: China
Brand Name: LKS / ODM / OEM
Certification: CE, FCC
Model Number: LKS8317
Payment & Shipping Terms:
Minimum Order Quantity: 5 units
Packaging Details: Film wrap, foam and wooden box
Delivery Time: 4-6 weeks upon payment
Payment Terms: T/T in advance
Supply Ability: 1000 units per month
  • Detail Information
  • Product Description

Detail Information

Cash Acceptor: MEI Brand Detection Rate: 98% Or Higher
Supportive Currency: International Currency Billnote Size: 67mm*158mm;71mm*158mm; 78*158mm
Coin Size: Coin Diameter: 15-31.5mm ( Optionally Up To 32.5mm) Other: Safe Box For Coin And Cash Currency
High Light:

atm kiosk

,

self service payment kiosk

Product Description



MEI Bill Validation Payment Kiosk User Friendly , Maintenance Free Machine

Standard Configuration :



  1. Industrial PC
  2. 19 inch monitor
  3. 19 inch touchable screen
  4. Webcam
  5. Receipt printer
  6. Bill validator / acceptor
  7. Coin validator / acceptor
  8. UPS
  9. IO control board
  10. Speaker
  11. Free standing single screen cabinet





Specification list as following:



Components Details
PC system Industrial Board Seavo/ Gigabyte/Advantech AIMB 562
CPU Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7
RAM 2GB /4 GB / 8GB
HDD 500G
Interface 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card
PC Power Supply HUNTKEY/Great Wall
LCD monitor Screen Size 19inch ( optional from 8inch to 65inch)
Brightness 250cd/m2
angle horizontal 100°above;Vertical 80°above
Contrast 1000:1
Backlight tube life more than 40,000hours
Max. resolution 1280×1024
Touch screen Screen Size 19 inch Diagonal ( optional from 8inch to 65inch)
Resolution 4096x4096
High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times
 Bill acceptor Validation Rate 96% or higher
Banknote Insertion Four-way
Escrow One banknote
Capacity 1000 notes Max
Coin Acceptor Coin Acceptance Max 32 coin types, in 2*16 or 1*32 channels
Detection ability of counterfeit Coins with high detection ability of counterfeit coins
Accepting Speed 2 Coins/Sec
Supply Voltage 10V-16V DC
Epson receipt thermal printer Autocutter included
Technology Thermal printing
Paper width 80mm
Printing speed 150mm/s
Data buffer 4KB
Interface RS232 ,USB
Camera HD webcam 500 million pixels
Speaker Amplifier 5w 8Ω
UPS Input voltage 145-290va
Output voltage 200-255va
Max time for supplying a single PC 3~20minutes (for single PC)
Digital Power Supply AC input voltage range 100~240VAC
Frequency 50Hz to 60Hz
AC input voltage range 100~240VAC
Frequency 50Hz to 60Hz
Sensor alarm system GSM module,making call and siren alert when kiosk broken into
Accessories Wire-lan port, USB ports, speakers, fans, cables, screws, etc.
Operation System Windows 7 or Windows XP operation system without license
KIOSK Cabinet Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request.
Packing Security Packing method with bubble foam and wooden case





Other Optional hardware components List of  MEI Bill Validation Payment Kiosk User Friendly,Maintenance Free Machine  is as following:



  1. Cash dispenser
  2. Coin dispenser
  3. Receipt printer
  4. Pinpad
  5. Bank card reader
  6. Check scanner
  7. Card Dispenser
  8. Advertising screen
  9. Barcode scanner
  10. Passport reader
  11. A4 Laser printer




Applications:

  • Banks
  • Convenience store
  • Hypermarket
  • Hotel
  • Bank
  • ATM / VTM / ITM booth
  • Supermarket
  • Bus station
  • School
  • Retail store
  • Fast food chain store
  • Hospital
  • Theater
  • Railway Station
  • Metro Station
  • Parking Lot
  • Shopping Mall





The reason you choose LKS:



  1. LKS has sheet metal and kiosk assembling factories,monthly productivity is more than 1,000 units;
  2. LKS has professional software development team which all members are with years experience,we make practical suggestions and provide best solutions by taking all factors into consideration.
  3. LKS has 100%  yearly growth rate during last three years,our partners come from bank like China Construction Bank, IT company like Alibaba;
  4. LKS is meant to internationalize its brand and company by providing unparalleled service ,like sending engineers at site to install and do maintenance if necessary;
  5. LKS has dozens of different samples in stock and delivery is within one week by just doing a little changes to suit your needs,besides there is no any extra sample fee for it;
  6. LKS has complete and standard procedure to proceed orders,we will send 3D drawing to you for confirmation before any production starts;
