Home > products > ATM Kiosk > Health Kiosk Information System Applications iPhone Displaying Interface Type

Health Kiosk Information System Applications iPhone Displaying Interface Type

Product Details

Place of Origin: China

Brand Name: LKS or customized

Certification: CE, FCC

Model Number: LKS8314

Payment & Shipping Terms

Minimum Order Quantity: 5Units

Packaging Details: Film wrap, foam and wooden box

Delivery Time: 4-6weeks upon payment

Payment Terms: T/T in advance, Western Union

Supply Ability: 1000 units per month

Get Best Price
Product Details
High Light:

patient registration kiosk

,

medical kiosk

Material:
1.5mm To 2.5mm Cold-roll Sheet Or Others
Application:
Indoor
Supported OS:
Windows 7 Or Windows 8 Or Linux
Power Supply:
110-120V, 220V-240V Or Optional
Color:
Gray (Optional)
Function:
Bill Payment Kiosk, Touchscreen Kiosk, Cash Dispenser Kiosk...
Material:
1.5mm To 2.5mm Cold-roll Sheet Or Others
Application:
Indoor
Supported OS:
Windows 7 Or Windows 8 Or Linux
Power Supply:
110-120V, 220V-240V Or Optional
Color:
Gray (Optional)
Function:
Bill Payment Kiosk, Touchscreen Kiosk, Cash Dispenser Kiosk...
Product Description

Health Kiosk Information System Applications iPhone Displaying Interface Type

 Standard configurtion:


  1. 19 inch LCD Monitor
  2. 19 inch IR touch screen
  3. USB port
  4. Receipt printer
  5. Manual Bank / Credit Card swipe reader
  6. 58 mm receipt printer ….
  7. Social card / ID reader
  8. Metal keyboard
  9. Free standing cabinet


Standard hardware components List is as following:



Components

Details

PC system

Industrial Board

Seavo / Gigabyte / Advantech,AIMB 562

CPU

Dual core E5700 / G2020, 2.8ghz; Intel Dual Core I3/I5/I7

RAM

2GB /4 GB / 8GB

HDD

500G

Interface

6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card

PC Power Supply

HUNTKEY / Great Wall

LCD monitor

Screen Size

19 inch ( optional from 8 inch to 65 inch)

Brightness

250 cd/m2

angle

horizontal 100°above;Vertical 80°above

Contrast

1000:1

Backlight tube life

more than 40,000 hours

Max. resolution

1280×1024

Touch screen

Screen Size

19 inch Diagonal ( optional from 8 inch to 65 inch)

Resolution

4096 * 4096

High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times

Metal keyboard

Keylift‐span

2,000,000 cycles

Key force

2~3N

Key trip

>2.5mm

Protection level

IP65

Operating Temperature

0° C to 40° C

Receipt thermal printer

Auto-cutter

included

Technology

Thermal printing

Paper width

58 mm

Printing speed

150 mm/s

Data buffer

4KB

Interface

RS232 ,USB

Bank card swipe readerMagnetic head life500,000 / min
IntefaceRS232
Power supply5 DV
ID / Social card readerTypeContactless IC card,NFC card,RF card
OtherSize:54*86mm

Digital Power Supply

AC input voltage range

100~240 VAC

Frequency

50 Hz to 60 Hz

AC input voltage range

100~240VAC

Frequency

50 Hz to 60 Hz

Accessories

Wire-lan port, USB ports, speakers, fans, cables, screws, etc.

Operation System

Windows 7 or Windows XP operation system without license

KIOSK Cabinet

Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request.

Packing

Security Packing method with bubble foam and wooden case



Other Optional hardware components List is as following:


  1. Barcode Scanner
  2. Cash / Coin acceptor
  3. Cash / Coin dispenser
  4. Web camera
  5. Card dispenser
  6. Contactless IC / NFC / RF Card reader
  7. Wireless Module
  8. Advertising screen
  9. A4 printer
  10. Photo printer
  11. Film printer
  12. Check scanner



Application:

  • Gas station
  • Metro Station
  • Parking Lot
  • Banks
  • Hospital
  • Shopping Mall
  • Movie Theater
  • Air port station
  • Railway Station
  • Hotel
  • Other Public areas


Our Advantages:
 Elegant Appearance


  • High-quality design sketch
  • Attractive decoration
  • Regular elegant design
  • Attract end customer
  • Multi-color processed surface
  • Human engineering verification


Low Cost Solution


  • Easy of Operation
  • Built on widely used stable prooven technology
  • Complete supply chain management
  • Modular design for easy maintenance
  • Stable-quality hardware components


Designed for 24 / 7 operation


  • vandal resistant components
  • Highly responsive user interaction
  • Tightly integrated hardware and software



 Description


  1. LKS Dual Screen Kiosks manufactured by 1.5mm-2.5mm thickness cold-roll steel sheets which ensure the stability and rigidity of all structure.
  2. LKS Dual Screen Kiosk is developed specifically for payment use in bank, hospital, convenient store, subway, railway station, metro station, parking Lot, theater, shopping mall, etc.
  3. LKS is a Dual Screen Kiosk manufacturers and ATM kiosk supplier in China. It provides the Self Service Kiosk with advertising screen brings a unique look to the different self-service kiosk applications and kiosk industry.
  4. LKS main Dual Screen Kiosk are including bill pay kiosk, pop up kiosk, touch screen self payment kiosk, touch screen bill payment terminal kiosk, self service payment kiosk, payment terminal kiosk, atm kiosk, swipe card reader kiosk, self payment terminal kiosk, wall mounted payment kiosk, free standing payment kiosk, prepaid kiosk, pin pad payment kiosk, subway kiosk; kiosk terminal; financial kiosk, etc.
