Dot Matrix Printer Tickets Vending Machine Kiosk Large Paper Capacity

Product Details

Place of Origin: China

Brand Name: LKS / ODM / OEM

Certification: CE, FCC

Model Number: LKS8383C

Payment & Shipping Terms

Minimum Order Quantity: 5Units

Packaging Details: Film wrap, foam and wooden box

Delivery Time: 4-6 weeks upon payment

Payment Terms: T/T in advance, Western Union

Supply Ability: 1000 units per month

Get Best Price
Product Details
High Light:

patient registration kiosk

,

medical kiosk

Function:
Self Card Payment,ticket Printing And Vending
Card:
Member Card Like Contactless IC,RF,NFC
Screen:
6-points IR Touchable
Brightness:
250 Cd/㎡
Material:
Cold Rolled Steel Or Stainless Steel
Other:
6 Hard Copies For A Ticket Maximum
Function:
Self Card Payment,ticket Printing And Vending
Card:
Member Card Like Contactless IC,RF,NFC
Screen:
6-points IR Touchable
Brightness:
250 Cd/㎡
Material:
Cold Rolled Steel Or Stainless Steel
Other:
6 Hard Copies For A Ticket Maximum
Product Description


Dot Matrix Printer Tickets Vending Machine Kiosk Large Paper Capacity,Maintenance Free


Standard configuration:


  1. 21.5 inch LCD Monitor
  2. 21.5 inch IR touch screen
  3. Industrious PC
  4. A4 dot matrix printer
  5. Speaker
  6. Webcam
  7. Social insurance card reader
  8. Member card reader
  9. Receipt printer
  10. Free standing cabinet


Standard hardware components List is as following:


Components

Details

PC system

Industrial Board

Seavo / Gigabyte / Advantech,AIMB 562

CPU

Dual core E5700 / G2020, 2.8ghz; Intel Dual Core I3/I5/I7

RAM

2GB /4 GB / 8GB

HDD

500G

Interface

6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card

PC Power Supply

HUNTKEY / Great Wall

LCD monitor

Screen Size

21.5 inch ( optional from 8 inch to 65 inch)

Brightness

250 cd/m2

angle

horizontal 100°above;Vertical 80°above

Contrast

1000:1

Backlight tube life

more than 40,000 hours

Max. resolution

1280×1024

Touch screen

Screen Size

21.5 inch Diagonal ( optional from 8 inch to 65 inch)

Resolution

4096 * 4096

High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times

Receipt printer

Papper material

Thermal paper

Paper width

80 mm

Printing speed

150 mm / s

Interface

RS232,USB

Paper length

As optional

A4 dot matrix  printer

Paper

A4 sheets maximum

Technology

Whitel and black dot matrix printing

Paper capacity

As optional

Printing speed

50 pages / m

Data buffer

4KB

Interface

RS232 ,USB

Member card readerTypeContactless IC card,NFC card,RF card
OtherSize:54*86mm
Social insurance card readerCard typeContact IC card reader
IC Card Touch Port300,000 / min
Read typeAutomatically inserting

Digital Power Supply

AC input voltage range

100~240 VAC

Frequency

50 Hz to 60 Hz

AC input voltage range

100~240VAC

Frequency

50 Hz to 60 Hz

SpeakerDual channel amplified speakers for Stereo , 8Ω 5W.
Webcam500 pixels,no driver needed

Accessories

Wire-lan port, Handset,USB ports, speakers, fans, cables, screws, etc.

KIOSK Cabinet

Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request.

Packing

Security Packing method with bubble foam and wooden case



Other Optional hardware components List is as following:


  1. Barcode Scanner
  2. Cash / Coin acceptor
  3. Cash / Coin dispenser
  4. Card dispenser
  5. Wireless Module like 3G,WLAN,GPRS,LTE
  6. Advertising screen on top
  7. ID scanner
  8. Fingerprint Reader
  9. Palm vein scanner
  10. Bank card reader
  11. UPS
  12. GSM sensor alarm system



Application:


  • Bus station
  • Citzen community
  • VTM / ATM booth
  • Supermarket
  • School
  • Metro Station
  • Parking Lot
  • Banks
  • Hospital
  • Shopping Mall
  • Movie Theater
  • Air port station
  • Railway Station
  • Hotel
  • Other Public areas



Our Advantages:

Designed for 24 / 7 operation

  • vandal resistant components
  • Highly responsive user interaction
  • Tightly integrated hardware and software


Low Cost Solution:

  • Built on widely used stable prooved technology
  • Complete supply chain management
  • Modular design for easy maintenance
  • Stable-quality hardware components


 Elegant Appearance

  • High-quality design sketch
  • Regular elegant design
  • Attract end customer
  • Multi-color processed surface
  • Human engineering verification



The reason you choose LKS:


  1. LKS has 100%  yearly growth rate during last three years,our partners come from bank like China Construction Bank, IT company like Alibaba;
  2. LKS has complete and standard procedure to proceed orders,we will send 3D drawing to you for confirmation before any production starts;
  3. LKS has professional software development team which all members are with years experience,we make practical suggestions and provide best solutions by taking all factors into consideration.
  4. LKS has sheet metal and kiosk assembling factories,monthly productivity is more than 1,000 units;
  5. LKS is meant to internationalize its brand and company by providing unparalleled service ,like sending engineers at site to install and do maintenance if necessary;
  6. LKS has dozens of different samples in stock and delivery is within one week by just doing a little changes to suit your needs,besides there is no any extra sample fee for it;
