Shenzhen Lean Kiosk Systems Co., Ltd. frank@lien.cn 00-86-18664576557
Product Details
Place of Origin: China
Brand Name: LKS / ODM / OEM
Certification: CE, FCC
Model Number: LKS8204Series
Payment & Shipping Terms
Minimum Order Quantity: 10 units
Packaging Details: Film Wrap,Foam and Wooden Box
Delivery Time: 4-6weeks upon payment
Payment Terms: T/T in Advance
Supply Ability: 1000-2000 units per month
Monitor Size: |
13.3 Inch |
Card: |
Contactless IC / RF,IC And Magnetic Stripe |
Receipt Paper: |
58mm Width |
Touch Screen: |
Singular Or Multiple Points IR Technology |
Card Reader: |
EMV Motorized |
OS: |
Android / Windows / Linux |
Monitor Size: |
13.3 Inch |
Card: |
Contactless IC / RF,IC And Magnetic Stripe |
Receipt Paper: |
58mm Width |
Touch Screen: |
Singular Or Multiple Points IR Technology |
Card Reader: |
EMV Motorized |
OS: |
Android / Windows / Linux |
Standard configuration:
Specification is as following:
| Components | Details | |
| PC system | Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 |
| CPU | Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7 | |
| RAM | 2GB /4 GB / 8GB | |
| HDD | 500G | |
| Interface | 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card | |
| PC Power Supply | HUNTKEY/Great Wall | |
| LCD monitor | Screen Size | 12 inch ( optional from 8inch to 65inch) |
| Brightness | 250cd/m2 | |
| angle | horizontal 100°above;Vertical 80°above | |
| Contrast | 1000:1 | |
| Backlight tube life | more than 40,000hours | |
| Max. resolution | 1280×1024 | |
| Touch screen | Screen Size | 12 inch Diagonal ( optional from 8inch to 65inch) |
| Resolution | 4096x4096 | |
| High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times | ||
| Bank/Credit Card Reader | Interface | RS232 |
| Card Type | Support Magcard, IC Card, RF Card, Mifare S50,S70,UL Card | |
| Power Voltage | DC 24V±5% | |
| Card Entry method | Magnetic signal, Optoelectronic signal and rear card signal | |
| Encrypted Pinpad | Keylift~span | 2,000,000 cycles |
| Key force | 2~3N | |
| Key trip | >2.5mm | |
| Protection level | ip65 | |
| Epson receipt thermal printer | Autocutter | included |
| Technology | Thermal printing | |
| Paper width | 80mm | |
| Printing speed | 150mm/s | |
| Data buffer | 4KB | |
| Interface | RS232 ,USB | |
| Digital Power Supply | AC input voltage range | 100~240VAC |
| Frequency | 50Hz to 60Hz | |
| AC input voltage range | 100~240VAC | |
| Frequency | 50Hz to 60Hz | |
| Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. | |
| Operation System | Windows 7 or Windows XP operation system without license | |
| KIOSK Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. | |
| Packing | Security Packing method with bubble foam and wooden case | |
Other Optional hardware components List is as following:
Multi-functional Application:
Our Advantages:
Suitable for 24 / 7 operation
Industrial modular components from worldwide famous brands
Function at a higher capacity and are fully integrated and more secure.
Cost-effective Solution
Ease of use,Outstanding and interactive Consumer/Customer seamless experience
Increase ROI
Appearance
The Reason you choose LKS:
LKS Factory Tour-Process Of Followsheet
LKS Factory Tour- Kiosk Mass Producing.
LKS Certificates :
LKS Factory tour-Receiption Desk.
LKS Office
LKS Shipping Terms
Welcome to contact us and send inquiry now!
