Shenzhen Lean Kiosk Systems Co., Ltd.

Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3

Product Details:
Place of Origin: China
Brand Name: LKS or customized
Certification: CE, FCC
Model Number: DV-PJ
Payment & Shipping Terms:
Minimum Order Quantity: 1unit
Price: USD+710-770+ Piece
Packaging Details: Film Wrap,Foam and Wooden Box
Delivery Time: 4-6weeks upon payment
Payment Terms: T/T in Advance
Supply Ability: 1000-2000 units per month
  • Detail Information
  • Product Description

Detail Information

Model Name: 46 55 Inch LCD Video Wall Panel Size: 46 49"55 "
Bazel Width: 0.8mm/1.7mm/1.8mm/3.5mm/5.3mm Resolution: 1080p FHD
Viewing Angle: 178° / 178° Response Time: 6.5 Ms
Interface: HDMI 2.0 / VGA/ DVI /CVBS( BNC) ,RS-232 (RJ45) LAN
High Light:

3.5mm Seamless Lcd Video Wall

,

1.8mm Seamless Lcd Video Wall

,

46" Shopping Mall Multi Screen Video Wall

Product Description

Shopping mall 46 49 55 inch 4K display 2x2 3x3 multi wall 1.8mm 3.5mm seamless lcd video wall
(DV-PJ




Product description



Feature Ultra-thin Bezel design to deliver maximum visual impact for all Digital Signage and Conference Collaboration Applications. With energy-saving LED Technology that enables 24hr a day operation, and Auto Standby for Image Burn Protection offer premium, reliable performance to meet all your commercial application demands.



Video wall has been widely used for lcd advertising display and CCTV monitoring system and we have full range of video wall on sale, support 7*24h working and random installation, can be installed on the wall or with a floorstanding cabinet. We will provide the full solution including processor/matrix, wall-mount bracket/floorstanding cabinet, processor, power cable, Lan cable, remote control and video wall setting adjustment software. Touchscreen is also on option.



Main features

1) Multi-screen Narrow seam stitch, whether it is a separate or splicing wall, it can greatly enhance the viewing effect.

2) A selection of IPS panels convering RGB wide color gamut up to 16.7million colors.

3) 178 degree no dead angle screen, the full range of display.

4) Intelligent split screen creative constant: Screen smart sub, arbitrary single screen, multi-screen, abitrary comnination intelligent splicing, a variety of ways to play a large number of.



Product Specification

Panel Size
46"
49"
55"
65"
Panel Brand
Samsung
LG
Samsung/LG
Samsung
Model
PJ460P
PJ490P
PJ550P
PJ650G
Pixel Pitch
0.53025*0.53025mm
0.55926*0.55926mm
0.63*0.63mm
0.372*0.372mm
Viewing Angle
178H/178V
Response Time
<6ms
Display Color
8Bit,16.7M
Contrast Ratio
3500:1
1300:1
4500:1
4000:1
Connectivity
HDMI/DVI/VGA/AV/RJ45/Audio/Display Port
Bezel Width
1.7mm/3.5mm
1.8mm/3.5mm
0.88mm/1.7mm/1.8mm/3.5mm
3.5mm
Brightness
500cd/m2&700cd/m2
500cd/m2&700cd/m2
500cd/m2&700cd/m2
700cd/m2
Resolution
1920*1080
1920*1080
1920*1080
3840*2160
Power supply
AC100-240V/50-60Hz
Sleep mode
0.5W
Max comsumption
180W
200w
220w
350w
Net weight
20kg
25kg
28kg
40kg
Working Temp
0-40℃
Working Humidity
10-90%
Operation
7x24hrs
Life
>60,000hrs
Warranty
Standard one year without artificial damage,can be extended to 3 years,lifelong maintenance

Products images

Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 0Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 1Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 2Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 3
Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 4Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 5Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 6Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 7Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 8
Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 9Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 10
Company introduction


About US

Shenzhen Lean Kiosk Systems Co., Ltd. (LKS) is a kiosk manufacturer as well as one of the selected groups of global companies at the front of the kiosk revolution. We design kiosk and also develop and distribute a wide range of high quality total solutions to over 30 countries worldwide, facilitating an easier adoption of Kiosk applications in different industries. Our factory address is Adress1: 1st Floor, No.99-15 Fu'an First Industrial Area, Yixin Zhongye Office Building, Dayang Road, Xintian Community, Fuhai Street, Baoan District, Shenzhen, China. Address2: Room 301, Building 45, Dayangtian Industrial Zone, Wanfeng Community. The size of our factory is about 5,000 to 10,000 sqaures. We have years of experience in kiosk field. LKS takes full ownership in the success of customers' programs from initial solution design to manufacturing and field services.LKS provides you with a variety of OEM services in low volume business. Let us be your China kiosk manufacture and kiosk design department, and we will help you to build your own brand!

Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 11

Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 12

Shopping Mall 1.8mm 3.5mm Seamless LCD Video Wall 46 49 55 Inch 2x2 3x3 13




1. Are you a factory or trading company? WITH SAMSUNG LG PANELS

We are a OEM/ODM manufacture.



2. What kind of payment terms?

Our payment term is TT(30% deposit before production, 70% balance before shipment), and westen union.



3. Lead time?

3-5 days for LCD video wall, 10 days for standard LCD monitor and LCD digital signage. 25 days for customized products.



4. Accept small order?

Yes, we accept small order, even one unit sample.



5. Do you give any discount

We aim to offer clients best price and best products service at the same time.



6.I would like to ask you if it's possible to have my logo on the product.

We hope you know that our company Asianda perfectly support customized logo service.



7. What's the shipment terms and delivery time of your company?

A: Well, they depends on the quantity of your order. As you know, we need time to manufac- ture the machines. but mostly, the shipment time is 3-8 working days after delivery. For De- livery way, for Sample and Bulk order 100KG, we will kindly suggestExpress and Air freight, when Air freight and Sea shipping for Bulk order >100KG. As for detailed cost, it de- pends on your tinal order.
