Product Details
Place of Origin: China
Brand Name: LKS or customized
Certification: CE, FCC
Model Number: LKS8218D
Payment & Shipping Terms
Minimum Order Quantity: 5 Units
Packaging Details: Film wrap, foam and wooden box
Delivery Time: 4-6 weeks upon payment
Payment Terms: T/T in advance, Western Union, L/C
Supply Ability: 1000 units per month
Material: |
Cold Rolled Steel Or Stainless Steel Or Others |
Material Feature: |
Anti-vandal, Anti-dust,Anti-acid,Waterproof |
Application: |
Indoor |
OS: |
Windows 7 / Windows 8 / Linux / Android 4.4.4 |
Display: |
LCD, TFT, LED |
Type Of Card: |
Smart Card Like IC And Magnetic Stripe Or RF Card ,contactless Card |
Touch Screen: |
IR / SAW / Capacitive / Resistent |
Warranty: |
12 Months After Delivery |
Power Supply: |
110-120V, 220V-240V Or Others |
Color And Logo: |
Customizable |
Function: |
Self Payment Wall Mounted Kiosk |
Type: |
Wall Mounted |
Size Of The Screen: |
15 Inch |
Card Reader Type: |
By Auto Inserting Or Swiping |
Material: |
Cold Rolled Steel Or Stainless Steel Or Others |
Material Feature: |
Anti-vandal, Anti-dust,Anti-acid,Waterproof |
Application: |
Indoor |
OS: |
Windows 7 / Windows 8 / Linux / Android 4.4.4 |
Display: |
LCD, TFT, LED |
Type Of Card: |
Smart Card Like IC And Magnetic Stripe Or RF Card ,contactless Card |
Touch Screen: |
IR / SAW / Capacitive / Resistent |
Warranty: |
12 Months After Delivery |
Power Supply: |
110-120V, 220V-240V Or Others |
Color And Logo: |
Customizable |
Function: |
Self Payment Wall Mounted Kiosk |
Type: |
Wall Mounted |
Size Of The Screen: |
15 Inch |
Card Reader Type: |
By Auto Inserting Or Swiping |
Standard configuration:
Specification is as following:
| Components | Details | |
| PC system | Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 |
| CPU | Dual core Intel Atom D525 | |
| RAM | 2GB | |
| HDD | 500G | |
| Interface | 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card | |
| PC Power Supply | HUNTKEY/Great Wall | |
| LCD monitor | Screen Size | 15 inch ( optional from 8inch to 65inch) |
| Brightness | 250cd/m2 | |
| angle | horizontal 100°above;Vertical 80°above | |
| Contrast | 1000:1 | |
| Backlight tube life | more than 40,000hours | |
| Max. resolution | 1280×1024 | |
| Touch screen | Screen Size | 15 inch Diagonal ( optional from 8inch to 65inch) |
| Resolution | 4096x4096 | |
| High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times | ||
| Receipt Printer | Interface | High Speed USB |
| Resolution | 4800*1200 maximum | |
| Printing speed | 4.8 ipm | |
| Width | 58 /80 /112 mm | |
| Length | Customizable | |
Webcam
|
Resolution | 1280*720 |
| Pixel | 8000000 | |
| Adaptive Resolution | 1280*720 | |
| Interface | USB 2.0 | |
| Driver | No | |
| Encrypting Pinpad | Keylift‐span | 2,000,000 cycles |
| Key force | 2~3N | |
| Key trip | >2.5mm | |
| Protection level | IP65 | |
| Operating Temperature | 0° C to 40° C | |
| Auto insert card reader | Interface | RS232 |
| Card Type | Support IC Card, RF Card, Mifare S50,S70,UL Card | |
| Magnetic Head Life | 500,000/min | |
| 500,000/min | 300,000/min | |
| Power Voltage | DC 24V±5% | |
| Magnetic swipe card reader | Card standard | ISO 7811/2 |
| Operation speed | 15-120 cm/sec (6-50inch/sec) | |
| Head life | At least 500,000 times | |
| Track | I(IATA), II (ABA), III (MINTS) | |
| Track location | ISO1 (IATA), ISO2 (ABA), ISO3 (MINTS) | |
| Track width | 1.5mm | |
| Card thickness | 0.76 ± 0.08 mm | |
| Contactless card reader | Interface | Support ISO14443 |
| Card Type | ISO14443TypeA of Contactless IC Card, including Mifare S50,Mifare S70,MF1ICL10,Mifare Pro,Mifare desfire,Mifare ultralight | |
| Status Display | LED indicator to show the power or communication status | |
| Operated Temperature | From -20 to +60ºC | |
| UPS | Input voltage | 145-290 V |
| Output voltage | 200-255 V | |
| Output frequency | 50±0.5Hz | |
| Transient time | 50±0.5Hz | |
| Max time for supplying a single PC | 3~20minutes (for single PC) | |
| Alarm system sensor / IO control board | Function | Door alarm sensor with enternet function, SIM,SMS,CALL |
| Speakers | Features | Dual channel amplified speakers for Stereo ,8Ω 5W |
| Digital Power Supply | AC input voltage range | 100~240VAC |
| Frequency | 50Hz to 60Hz | |
| AC input voltage range | 100~240VAC | |
| Frequency | 50Hz to 60Hz | |
| Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. | |
| Operation System | Windows 7 or Windows XP operation system without license | |
| Wall mounted Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. | |
| Package | Security Packing method with bubble foam and wooden case | |
Other Optional hardware components List is as following:
Description
Multi-function:
Our Advantages:
Design for 24 / 7 application:
Cost-effective Solution
Appearance
