Self-service Passport scanner Terminal

Product Details:
Place of Origin: China
Brand Name: LKS or customized
Certification: CE, FCC
Model Number: LKS8501A
Payment & Shipping Terms:
Minimum Order Quantity: 5 Units
Packaging Details: Film wrap, foam and wooden box
Delivery Time: 4-6 weeks upon payment
Payment Terms: T/T in advance, Western Union, L/C
Supply Ability: 1000 units per month
  • Detail Information
  • Product Description

Detail Information

12 Inch Screen: Capacitive Touchable 22 Inch Screen: LED / LCD TFT Monitor
Type: Free Standing Dual Screen Kiosk Cheque: Scan And Storage
Billnote: Validate And Accept Receipt Printer: 80 Mm Width
High Light:

touch screen kiosk

,

digital signage kiosk

Product Description



Self-service Passport scanner Terminal



Standard configuration:



  1. 22  inch monitor
  2. 12 inch monitor
  3. 12 inch touch screen
  4. Webcam
  5. Industrious PC
  6. Cheque scanner
  7. Speaker
  8. Billnotes validator
  9. Receipt printer
  10. Encrypting Pinpad
  11. Manual smart card reader
  12. Member card reader
  13. UPS
  14. Alarm system sensor
  15. Free standing dual screen cabinet





Specification  is as following:



Components Details
PC system Industrial Board Seavo/ Gigabyte/Advantech AIMB 562
CPU Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7
RAM 2GB /4 GB / 8GB
HDD 500G
Interface 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card
PC Power Supply HUNTKEY/Great Wall
LCD monitor Screen Size 12 inch/22 inch ( optional from 8inch to 65inch)
Brightness 250cd/m2
angle horizontal 100°above;Vertical 80°above
Contrast 1000:1
Backlight tube life more than 40,000hours
Max. resolution 1280×1024
Touch screen Screen Size 12 inch Diagonal ( optional from 8inch to 65inch)
Resolution 4096x4096
High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times
Receipt Printer Interface High Speed USB
Resolution 4800*1200 maximum
Printing speed 4.8 ipm
Width 58 /80 /112 mm
Length Customizable

Webcam



Resolution 1280*720
Pixel 8000000
Adaptive Resolution 1280*720
Interface USB 2.0
Driver No
Encrypting Pinpad Keylift‐span 2,000,000 cycles
Key force 2~3N
Key trip  >2.5mm
Protection level IP65
Operating Temperature  0° C to 40° C
Manual card reader Interface RS232
Card Type Support Magcard, IC Card, RF Card,  Mifare S50,S70,UL Card
Magnetic Head Life 500,000/min
500,000/min 300,000/min
Power Voltage  DC 24V±5%
Cash acceptor Validation Rate 98% or higher
Banknote size Width: 62or 71mm; Length:120-160mm
Detection ability High detection of forged bills
Bill Escrow one bill
Cashbox capacity 1000  banknotes max
Operating Voltage  12V DC  or 24V AC
Operating Temperature 0° C to 55 ° C  (12 V DC platform);  -18° C to +60 ° C  (24 V AC platform)
Cheque scanner/acceptor Media size Width:60~110mm;Length:130~230mm;Thickness:0.08~0.13mm
Image scan Range:A6 size(105mm),Duplex scan
Method:Color CIS(control image sensor)
Resolution:200 dpi basic spec,256 gray scale
Speed:500mm/s
MICR recognition E138&CMC7
Interface USB high speed
Encrypted Pinpad Keylift-span 2,000,000 cycles
Rating IP65 waterproof
Interface RS232,USB
Keys 16 keys
Others LED status indication
Member card reader Card type Contactlss IC ,RF / NFC card
Standard ISO14443TypeA of Contactless IC Card, including Mifare S50,Mifare S70,MF1ICL10,Mifare Pro,Mifare desfire,Mifare ultralight
Status Display LED indicator to show the power or communication status
UPS Input voltage 145-290 V
Output voltage 200-255 V
Output frequency 50±0.5Hz
Transient time 50±0.5Hz
Max time for supplying a single PC 3~20minutes (for single PC)
Alarm system sensor / IO control board Function Door alarm sensor with enternet function, SIM,SMS,CALL
Speakers Features Dual channel amplified speakers for Stereo ,8Ω 5W
Digital Power Supply AC input voltage range 100~240VAC
Frequency 50Hz to 60Hz
AC input voltage range 100~240VAC
Frequency 50Hz to 60Hz
Accessories Wire-lan port, USB ports, speakers, fans, cables, screws, etc.
Operation System Windows 7 or Windows XP operation system without license
Free standing Cabinet Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request.
Package Security Packing method with bubble foam and wooden case




Other Optional hardware components List is as following:



  1. Barcode scanner
  2. Cash dispenser
  3. Palm vein scanner
  4. WIFI or 3G Wireless module
  5. Coin dispenser
  6. ID / Driver licence / Social insurance card double-side scanner
  7. Intercom
  8. Contactless card reader


Description


  1. LKS is a Dual Screen Kiosk manufacturers and ATM kiosk supplier in China. It provides the Self Service Kiosk with advertising screen brings a unique look to the different self-service kiosk applications and kiosk industry.
  2. LKS Dual Screen Kiosk is developed specifically for payment use in bank, hospital, convenient store, subway, railway station, metro station, parking Lot, theatre, shopping mall, etc.
  3. LKS Dual Screen Kioskis manufactured by 1.5mm-2.5mm thickness cold-roll steel sheets which ensure the stability and rigidity of all structure.
  4. LKS main Dual Screen Kiosk are including bill pay kiosk, pop up kiosk, touch screen self payment kiosk, touch screen bill payment terminal kiosk, self service payment kiosk, payment terminal kiosk, atm kiosk, swipe card reader kiosk, self payment terminal kiosk, wall mounted payment kiosk, free standing payment kiosk, prepaid kiosk, pin pad payment kiosk, subway kiosk; kiosk terminal; financial kiosk, etc.


Multi-function:


  • School
  • Pharmacy
  • Clinic
  • ATM / VTM / ITM booth
  • Airplane boarding room
  • High railway waiting room
  • Tourism sites
  • Hospital
  • Bank
  • Retailer store
  • Human resources room
  • Shopping Mall
  • Railway Station
  • Metro Station
  • Parking Lot
  • Bus station
  • Other Public area


Our Advantages:


Suitable for  24 / 7 excution:

  • Inner air recycling design for heat and humidity control
  • Alarm system sensor with reporting function
  • Less power consuming and more stable Industrious modules
  • Fixed on floor and lockable


Cost-effective Solution:

  • Independent modular hardward components
  • Complete and competitive supply chain management
  • Easy maintenance
  • Popular enclosure design


 Appearance:

  • Anti-vandal
  • Eyesight attractive
  • Brand promotion
  • Multi-color and customizable decorations
  • High-quality design sketch
  • Elegant and unique design





The Reason Why You choose LKS:



  1. LKS has 100%  yearly growth rate during last three years,our partners come from bank like China Construction Bank, IT company like Alibaba;
  2. LKS is meant to internationalize its brand and company by providing unparalleled service ,like sending engineers at site to install and do maintenance if necessary;
  3. LKS has dozens of different samples in stock and delivery is within one week by just doing a little changes to suit your needs,besides there is no any extra sample fee for it;
  4. LKS has complete and standard procedure to proceed orders,we will send 3D drawing to you for confirmation before any production starts;
  5. LKS has professional software development team which all members are with years experience,we make practical suggestions and provide best solutions by taking all factors into consideration.
