Shenzhen Lean Kiosk Systems Co., Ltd.

Cinema Interactive Information Kiosk Card Payment , Ticket Collecting Terminals

Product Details:
Place of Origin: China
Brand Name: LKS / OEM / ODM
Certification: CE, FCC
Model Number: LKS809B
Payment & Shipping Terms:
Minimum Order Quantity: 5 Units
Packaging Details: Film wrap, foam and wooden box
Delivery Time: 4-6 weeks upon payment
Payment Terms: T/T in advance, Western Union, L/C
Supply Ability: 1000 units per month
  • Detail Information
  • Product Description

Detail Information

Material: Cold Rolled Steel Or Stainless Steel Or Others Application: Indoor
Warranty: 12 Months After Delivery Power Supply: 110-120V, 220V-240V Or Others
Color And Logo: Customizable Type: Top Up Dual Screen Kiosk
Size Of The Banknote: Width: 62or 78mm; Length:160-180mm
High Light:

card dispenser kiosk

,

picture printing kiosk

Product Description

Cinema Interactive Information Kiosk Card Payment , Ticket Collecting Terminals



Standard configuration:


  1. 19 inch monitor
  2. 17 inch monitor
  3. 17 inch IR touch screen
  4. Industrious PC,2G RAM,500G HDD
  5. Wireless module like 3G / GPRS,WIFI,Blurtooth
  6. Speaker
  7. POS terminal
  8. NFC card reader
  9. Free standing dual screen cabinet


Specification  is as following:


ComponentsDetails
PC systemIndustrial BoardSeavo/ Gigabyte/Advantech AIMB 562
CPU Intel Dual Core I5
RAM4 GB
HDD500G
Interface6 RS-232 Ports;1 LTP;6 USB Ports,1 10/1000M Net Port ;Integrated Net Card, Sound Card
PC Power SupplyHUNTKEY/Great Wall
LCD monitorScreen Size17 inch ( optional from 8inch to 65inch)
Brightness250cd/m2
anglehorizontal 100°above;Vertical 80°above
Contrast1000:1
Backlight tube lifemore than 40,000hours
Max. resolution1280×1024
Touch screenScreen Size17 inch Diagonal ( optional from 8inch to 65inch)
Resolution4096x4096
High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times
Bank card readerStatus DisplayLED indicator to show the power or communication status
Card Type ISO14443TypeA of Contactless IC Card, including Mifare S50,Mifare S70,MF1ICL10,Mifare Pro,Mifare desfire,Mifare ultralight
TypeSupport  ISO14443
Wireless module3G module1, Compatible with HSUPA, HSDPA, UMTS, EDGE, GPRS, GSM network
2, Browsing Internet at high speed of 7.2Mbps downlink and 5.76Mbps uplink rate in max
3, Sending and receiving short messages
4, Managing contacts
Interface: USB2.0, and USB1.1 compatible
Data transmission: Transmission rate will be depended on the live network
SpeakersFeaturesDual channel amplified speakers for Stereo ,8Ω 5W
Digital Power SupplyAC input voltage range100~240VAC
Frequency50Hz to 60Hz
AC input voltage range100~240VAC
Frequency50Hz to 60Hz
AccessoriesWire-lan port, USB ports, speakers, fans, cables, screws, etc.
Operation SystemWindows 7 or Windows XP operation system without license
Free standing CabinetDurable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request.
PackageSecurity Packing method with bubble foam and wooden case



Other Optional hardware components List is as following:


  1. Dot matrix printer
  2. Cash acceptor / dispenser
  3. Coin acceptor / dispenser
  4. Palm vein scanner
  5. Fingerprint scanner
  6. Manual magnetic stripe swipe card reader
  7. ID / Driver licence / Social insurance card double-side scanner
  8. Passport scanner
  9. Encrypted Pinpad
  10. Stainless metal keyboad with track ball or touch pad
  11. Digital signature pad
  12. Cheque scanner / acceptor with MICR function



Application


  • Cinema
  • Hypermarket
  • Home supply store
  • Museum
  • Supermarket
  • Financial agency
  • Retailer store
  • Coffe shop
  • Park
  • Gymnasium
  • Conference lobby
  • Exibition
  • Coffe shop
  • Shopping Mall
  • Railway Station
  • Metro Station
  • Parking Lot
  • Bus station
  • Other Public area


Our Advantages:

Design for  24 / 7 Operation

  • Fixed on floor and lockable
  • Integrated industrial level compenents from worldwide famouse brands
  • Inner air recycling design for heat and humidity control
  • Alarm system sensor with instant reporting function


Cost-saving solution

  • No staff invloving
  • Ease-of-use,maintenance free
  • Design and production on our own
  • Two screen controls under only one PC
  • CE,FCC RoHS certification



The reason to choose LKS:

  1. LKS is meant to internationalize its brand and company by providing unparalleled service ,like sending engineers at site to install and do maintenance if necessary;
  2. LKS has professional software development team which all members are with years experience,we make practical suggestions and provide best solutions by taking all factors into consideration;
  3. LKS has dozens of different samples in stock and delivery is within one week by just doing a little changes to suit your needs,besides there is no any extra sample fee for it;
  4. LKS has complete and standard procedure to proceed orders,we will send 3D drawing to you for confirmation before any production starts;
  5. LKS has sheet metal and kiosk assembling factories,monthly productivity is more than 1,000 units;
  6. LKS has 100%  yearly growth rate during last three years,our partners come from bank like China Construction Bank, IT company like Alibaba,overseas like Oscar.



Appearance
Cinema Interactive Information Kiosk Card Payment , Ticket Collecting Terminals 0

LKS Factory Tour-Process Of Followsheet
Kiosk Design Ideas
LKS Factory Tour- Kiosk Mass Producing.
Kiosk Design Ideas
Kiosk Design Ideas
Kiosk Design Ideas
LKS Certificates :
1
LKS Factory tour-Receiption Desk.
reception
LKS Office
office new
LKS Shipping Terms
Kiosk Design Ideas
