Hospital self-service printer kiosk

Basic Information
Place of Origin: China
Brand Name: LKS or customized
Certification: CE, FCC
Model Number: LKS8564
Minimum Order Quantity: 10 units
Price: USD+5000+untis
Packaging Details: Film Wrap,Foam and Wooden Box
Delivery Time: 4-6weeks upon payment
Payment Terms: T/T in Advance
Supply Ability: 1000-2000 units per month
Operating System: Windows Or Android Input Device: Infrared Touch Panel
Size Of Touch Screen: 15",17",19" Or Upon Clients Brightness: 250 Cd/㎡
Logo: By Customers Needs Material Feature: Anti-dust, Anti-vandal
High Light:

card dispenser kiosk

,

photo booth kiosk



High Brightness Android Stand Card Reader Kiosk For Queue



Android Stand Card Reader Kiosk For Queue is widely used in many public places like banks, hotels, companies, schools, subways ect. Touch technology can be added according to customer's requirements to reach the interactive use of the shock effect. Exterior and functions extension can be done according to customer's requirements.



Standard hardware components List of LKS Android Stand Card Reader Kiosk For Queue  is as following:



Components Details
PC system Industrial Board Seavo/ Gigabyte/Advantech AIMB 562
CPU Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7
RAM 2GB /4 GB / 8GB
HDD 500G
Interface 6* RS-232 Ports;1* LTP;6 * USB Ports,8*GPIO;1*PCI
PC Power Supply HUNTKEY/Great Wall
RFID Card Reader Reading distance >4cm
Operating system windows98,Me ,XP,2003 ,Unix and Linux
Card contact number 200000 Secondary
Operating temperature -20℃ to 60℃
Whether contact Non-contact
Interface Serial ports,USB
Touch screen Screen Size 17/19 inch Diagonal ( optional from 8inch to 65inch)
Touch accuracy center: <1.5mm
edge: <3.2mm
Response time <16ms
Voltage DC5V+/-5%
Interface RS232,USB
Glass thickness 3mm
Resolution 4096x4096
Receipt printer Autocutter included
Technology Thermal printing
Paper width 80mm
Printing speed 150mm/s
Paper thickness 0.06-0.15mm
Supply voltage DC24V
Passport Scanner Product Type Flatbed color image sensor
Host interface USB ( Universal Serial Bus)
Image Sensor CMOS CIS ( Contact image sensor)
Resolution hardware optical 600dpi
Paper thickness >0.1mm
Scanning area 5.0"maximum scan width and 3" maximum scan length
wireless module TP-Link-GP-WB223MS
Accessories Wire-lan port, USB ports, speakers, fans, cables, screws, etc.
Operation System Windows 7 or Windows XP operation system without license
KIOSK Cabinet Durable steel frame, Slim and smart design; Easy to install and operate; Moistureproof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request.
Packing Security Packing method with bubble foam+wooden case




Android Stand Card Reader Kiosk For Queue Optional Hardware​ :

    Main components​​ ​​:

  1. Industrious PC
  2. 32 inch monitor
  3. 19inch IR touch screen
  4. Speaker
  5. Free standing single screen cabinet
  6. Wireless Module
  7. Movie Ticket Printer
  8. Receipt Printer
  9. Full-contactless IC Card Reader
  10. ID Card Reader
  11. Barcode Scanner
  12. Encrypted Pin Pad

Process of followsheet of LKS Android Stand Card Reader Kiosk For Queue​ ​ :




 Mass producing of LKS Android Stand Card Reader Kiosk For Queue​​  :







 Welcome to contact us and send inquiry now!
