Product Details
Place of Origin: China
Brand Name: LKS / ODM / OEM
Certification: CE, FCC
Model Number: LKS8500Series
Payment & Shipping Terms
Minimum Order Quantity: 10 units
Packaging Details: Film Wrap,Foam and Wooden Box
Delivery Time: 4-6weeks upon payment
Payment Terms: T/T in Advance
Supply Ability: 1000-2000 units per month
OS: |
Windows 8 / Windows 10 / Linux |
Card Type: |
Almightiness Card Like IC,RF,MS |
Card Storage: |
360~1000 Units As Optional |
Card Size: |
54*86*0.8 Mm ISO Standard |
Card Dispensing: |
Less Than 7 Seconds / Unit |
Other: |
Custom Design Are Offered On Demand |
Cash: |
Support Cash Payment |
OS: |
Windows 8 / Windows 10 / Linux |
Card Type: |
Almightiness Card Like IC,RF,MS |
Card Storage: |
360~1000 Units As Optional |
Card Size: |
54*86*0.8 Mm ISO Standard |
Card Dispensing: |
Less Than 7 Seconds / Unit |
Other: |
Custom Design Are Offered On Demand |
Cash: |
Support Cash Payment |
Standard configuration:
Specification is as following:
Components | Details | |
PC system | Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 |
CPU | Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7 | |
RAM | 2GB /4 GB / 8GB | |
HDD/SSD | 1TB, SSD 128G/256G | |
Interface | 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card | |
PC Power Supply | HUNTKEY/Great Wall | |
LCD monitor | Screen Size | 24 inch ( optional from 8inch to 65inch) |
Brightness | 250cd/m2 | |
angle | horizontal 100°above;Vertical 80°above | |
Contrast | 1000:1 | |
Backlight tube life | more than 40,000hours | |
Max. resolution | 1280×1024 | |
Touch screen | Screen Size | 24 inch Diagonal ( optional from 8inch to 65inch) |
Resolution | 4096x4096 | |
High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times | ||
Receipt Printer | Interface | High Speed USB |
Resolution | 4800*1200 maximum | |
Printing speed | 4.8 ipm | |
Width | 58 /80 /112 mm | |
Length | Customizable | |
Webcamera
|
Resolution | 1280*720 |
Pixel | 8000000 | |
Adaptive Resolution | 1280*720 | |
Interface | USB 2.0 | |
Driver | No | |
Encrypting Pinpad | Keylife‐span | 2,000,000 cycles |
Key force | 2~3N | |
Key trip | >2.5mm | |
Protection level | IP65 | |
Operating Temperature | 0° C to 40° C | |
Motorized card reader | Interface | RS232 |
Card Type | Support Magcard, IC Card, RF Card, Mifare S50,S70,UL Card | |
Magnetic Head Life | 500,000/min | |
500,000/min | 300,000/min | |
Power Voltage | DC 24V±5% | |
Cash acceptor | Validation Rate | 98% or higher |
Banknote size | Width: 62or 71mm; Length:120-160mm | |
Detection ability | High detection of forged bills | |
Bill Escrow | one bill | |
Cashbox capacity | 1000 banknotes max | |
Operating Voltage | 12V DC or 24V AC | |
Operating Temperature | 0° C to 55 ° C (12 V DC platform); -18° C to +60 ° C (24 V AC platform) | |
Card dispenser | Interface | RS232 |
Card specification | 86mm×54mm×0.2-1.8mm | |
Working environment | From -30°C to 70°C | |
ID scanner / Reader | ID scanner | 500 million,resolution 2592X1944 |
Scan size | A4 maximum | |
Image output | JPG,BMP,TIF,PDF,TGA,PCX,PNG,RAS type;color,gray ,monochrome; | |
Sensor | CMOS | |
OCR | Extract text to word file | |
Interface | USB 2.0 | |
UPS | Input voltage | 145-290 V |
Output voltage | 200-255 V | |
Output frequency | 50±0.5Hz | |
Transient time | 50±0.5Hz | |
Max time for supplying a single PC | 3~20minutes (for single PC) | |
IO control board | Function | Door alarm sensor with enternet function |
Speakers | Features | Dual channel amplified speakers for Stereo ,8Ω 5W |
Digital Power Supply | AC input voltage range | 100~240VAC |
Frequency | 50Hz to 60Hz | |
AC input voltage range | 100~240VAC | |
Frequency | 50Hz to 60Hz | |
Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. | |
Operation System | Windows 7 or Windows XP operation system without license | |
Free standing Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. | |
Package | Security Packing method with bubble foam and wooden case |
Hot! Elegant Bill Payment Kiosk with Cash,Free standing&wall mounted design ,Cost-effective ATM Kiosk,One-stop solution
Other Optional hardware components List is as following:
Other Applications
Advantages:
Help cut the lines,Serve customers with mininal involvement from staff
Desigh for higher standard and have a much longer life-cycle,with commecial-grade electronics
Display all preferences and items effectively,Increase sales opportunities and boosts the possibilities of repeat customers
