Home > products > Payment Kiosk > A4 Laser Printer Telekiosk Bill Acceptor Payment Kiosk , 3 Tracks USB MSR Wireless Card Reader

A4 Laser Printer Telekiosk Bill Acceptor Payment Kiosk , 3 Tracks USB MSR Wireless Card Reader

Product Details

Place of Origin: China

Brand Name: LKS or customized

Certification: CE, FCC

Model Number: LKS8564L

Payment & Shipping Terms

Minimum Order Quantity: 10 units

Packaging Details: Film Wrap,Foam and Wooden Box

Delivery Time: 4-6weeks upon payment

Payment Terms: T/T in Advance

Supply Ability: 1000-2000 units per month

Get Best Price
Product Details
High Light:

cash payment kiosk

,

atm kiosk

Product Description

A4 Laser Printer Telekiosk Bill Acceptor Payment Kiosk , 3 Tracks USB MSR Wireless Card Reader




Main functions :

  1. Type: Free standing kiosk, Bill Payment Kiosk, Touchscreen kiosk
  2. Application: Indoor
  3. Supported OS: Win 7 or  Win 8 or Linux
  4. optional size of screen: 15",  17", 19" or upon customers’ request
  5. Touch Screen: IR / SAW / Capacitive
  6. Display:Samsung / LG / CHIMEI / AUO
  7. Touch Screen: Saw / IR/ Optical touch screen
  8. Kiosk Color: Chooseable for kiosk frame
  9. Material Feature: Moisture proof, Antirust, Anti-acid, Anti-dust
  10. Material of Cabinet:1.5mm to 2.5mm Cold-roll sheet or stainless steel or others
  11. Logo:By customer’s needs
  12. Parts: Cash acceptor / Coin acceptor/Card reader/receipter printer….
  13. Warranty: 1 year
  14. Power supply: 110-120V, 220V-240V or optional


Customize Options:


  1. Personalized colors, finish, Logo & advertising
  2. PC upgrade
  3. Flexibility in customization and size of order
  4. Touch Screen size
  5. Integrated components
  6. Operating system
  7. Lockable computer & monitor & compartments



Description:


(1). Bill  payment kiosk with bill acceptor,card reader bill payment kiosk machine,self-service payment kiosk terminal will suit your particular needs and requirements - ranging from simple public internet access orinteractive payment kiosk to highly sophisticated public information delivery systems.

(2). Shenzhen Lean Kiosk System Co., Ltd is the professional touch screen bill payment kiosk manufacturer and also the leader in the kiosk industry in Shenzhen,China.Our product line includes all kinds of self-service touch screen payment kiosk machines and also ATM.

(3). If you are looking for a professional kiosk manufacturer of touch screen kiosk for your information orinternet kiosk project,payment kiosk project and bill payment kiosk project. Please feel free to contact me,we will assist you with all your touch screen payment kiosk requirements.


Applications:


  • On-Line Banking Kiosk
  • Order Entry Kiosk
  • Bill Payment Kiosk
  • Marketing Kiosk
  • Custom Kiosks
  • Directory Wayfinder Kiosk
  • Standing Payment Kiosk
  • Employee Self-Service Kiosk
  • Gaming Kiosk
  • Prepaid Kiosk
  • Redemption Kiosk
  • Retail Kiosk
  • Security Kiosk
  • Self-Service Kiosk
  • Ticketing Kiosk
  • Tourism Kiosk


Telekiosk Bill Acceptor Payment Kiosk With 3 Tracks USB MSR Wireless Card Reader A4 Laser Printer was designed having in mind the components that can integrate. The transact is the chameleon of the kiosks, because it can easily adapt the needs of each client.

Standard hardware components List of Telekiosk Bill Acceptor Payment Kiosk With 3 Tracks USB MSR Wireless Card Reader A4 Laser Printer is as following:


ComponentsDetails
PC systemIndustrial BoardAdvantech AIMB 562/Seavo H6116/ Gigabyte
CPUIntel Dual- Core G2020 ,2.9GHZ
RAM2GB /4 GB /8GB
HDD320G / 500G
Interface2 RS-232 Ports;1 LTP;4 USB Ports,1 10/100M Net Port
PC Power SupplyGreat Wall / HUNTKEY
LCD displayanglehorizontal 100°above;Vertical 80°above
Brightness250cd/m2
Screen Size17 inch/19inch  or other size
Contrast1000:01:00
Backlight tube life>  40,000hours
Max. resolution1280×1024 or 1920*1080
TouchscreenScreen Size17/19 inch Diagonal  or other size
Resolution4096x4096
High precision and durability, high Transparence , Orientation precision less than 2mm(0.080 inch); pure tempered glass;Single-point touch Life expectancy > 50,000,000 times
Bank/Credit Card ReaderInterfaceRS232 or USB
Card TypeSupport IC Card, Magcard,  Mifare S50,S70, RF Card, UL Card
Card Entry methodMagnetic signal, Optoelectronic signal and rear card signal
CertificateEMV level.1
Encrypted PinpadKeylift~span2,000,000 cycles
CertificatePCI 2.0
Key trip>2.5mm
Protection levelip65
Epson thermal printerAutocutterincluded
TechnologyThermal printing
Paper width80mm
Printing speed150mm/s
Data buffer4KB
InterfaceRS232 ,USB
1D / 2D bar code scanner
Digital Power SupplyAC input voltage range 100~240VAC
Frequency50Hz to 60Hz
Accessories (IO control board) USB ports, speakers, screws, fans, cables, Wire-lan port, etc.
Operation SystemWin 7 or Win 8 operation system without license
KIOSK CabinetDurable all steel anti-graffiti enclosure, Slim and smart design; Easy to install and operate; Moisture proof, Antirust, Anti-acid, Anti-dust,Static free,  color and LOGO upon clients request
PackingSecurity Packing method wooden case with bubble foam


 Other Optional hardware components List of Building Directory And Wayfinding Kiosk Self-service Betting Terminals Gambling Bill Payment Kiosk With QR Scanner  is as following:


  1. Cash acceptor
  2. Receipt Printer
  3. Webcomera
  4. Telephone
  5. Stripe Card reader
  6. A4 Printer
  7. Fingerprinter reader
  8. Light Box


Main designs of Telekiosk Bill Acceptor Payment Kiosk With 3 Tracks USB MSR Wireless Card Reader A4 Laser Printer
A4 Laser Printer Telekiosk Bill Acceptor Payment Kiosk , 3 Tracks USB MSR Wireless Card Reader 0
