Product Details
Place of Origin: China
Brand Name: LKS / ODM / OEM
Certification: CE, FCC
Model Number: LKS8598A
Payment & Shipping Terms
Minimum Order Quantity: 5 Units
Packaging Details: Film wrap, foam and wooden box
Delivery Time: 4-6 weeks upon payment
Payment Terms: T/T in advance, Western Union, L/C
Supply Ability: 1000 units per month
Card: |
Contactless IC, EMV Contact IC,Magnetic |
Card Reader: |
Bank Card Returned When Power Cut-off |
Card Size: |
ISO Standard 86*54*0.8 Mm |
EPP: |
PCI Certification |
Security: |
Stainless Privacy 16 Functional Keys Pinpad |
Other: |
Cash And Coin Out From One Single Exit |
Card: |
Contactless IC, EMV Contact IC,Magnetic |
Card Reader: |
Bank Card Returned When Power Cut-off |
Card Size: |
ISO Standard 86*54*0.8 Mm |
EPP: |
PCI Certification |
Security: |
Stainless Privacy 16 Functional Keys Pinpad |
Other: |
Cash And Coin Out From One Single Exit |
Standard configuration:
Standard specification is as following:
| Components | Details | |
| PC system | Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 |
| CPU | Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7 | |
| RAM | 2GB /4 GB / 8GB | |
| HDD | 500G | |
| Interface | 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card | |
| PC Power Supply | HUNTKEY/Great Wall | |
| LCD monitor | Screen Size | 19inch ( optional from 8inch to 65inch) |
| Brightness | 250cd/m2 | |
| angle | horizontal 100°above;Vertical 80°above | |
| Contrast | 1000:1 | |
| Backlight tube life | more than 40,000hours | |
| Max. resolution | 1280×1024 | |
| Touch screen | Screen Size | 19 inch Diagonal ( optional from 8inch to 65inch) |
| Resolution | 4096x4096 | |
| High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times | ||
| Bank/Credit Card Reader | Interface | RS232 |
| Card Type | Support Magcard, IC Card, RF Card, Mifare S50,S70,UL Card | |
| Power Voltage | DC 24V±5% | |
| Card Entry method | Magnetic signal, Optoelectronic signal and rear card signal | |
| Encrypted Pinpad | Keylift~span | 2,000,000 cycles |
| Key force | 2~3N | |
| Key trip | >2.5mm | |
| Protection level | ip65 | |
| Bill acceptor | Validation Rate | 96% or higher |
| Banknote Insertion | Four-way | |
| Escrow | One banknote | |
| Capacity | 1000 notes Max | |
| Bill dispenser | Denominations | 1.2.3.4 denominations to be dispensed as optional |
| Cassette capacity | 600 ~ 3000 billnotes as optional | |
| Dispensing speed | Less than 2 seconds / billnote | |
| Billnote dimension | width: 100-162mm; height: 62-78mm | |
| Interface | RS232 | |
| Coin dispenser | Coin capacity | 1500 coins maximum |
| Coin dimmension | Diameter: 18-28.5mm; Thickness: 1.65-3.2mm | |
| Interface | RS232 | |
| Dot matrix printer | Printing dimension | Width:145 mm maximum |
| Auto cutter | Full or half cut | |
| Printing speed | 480 letters / second | |
| Interface | RS232 | |
| Epson receipt thermal printer *2 | Autocutter | included |
| Technology | Thermal printing | |
| Paper width | 80mm | |
| Printing speed | 150mm/s | |
| Data buffer | 4KB | |
| Interface | RS232 ,USB | |
| Pinhole camera | Resolution | PAL: 976(H)*582(V) NTSC: 976(H)*494(V) |
| Focal distance | 3.7mm | |
| SNR | >52dB | |
| UPS | Input voltage | 145-290va |
| Output voltage | 200-255va | |
| Max time for supplying a single PC | 3~20minutes (for single PC) | |
| Digital Power Supply | AC input voltage range | 100~240VAC |
| Frequency | 50Hz to 60Hz | |
| AC input voltage range | 100~240VAC | |
| Frequency | 50Hz to 60Hz | |
| Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. | |
| Operation System | Windows 7 or Windows XP operation system without license | |
| KIOSK Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. | |
| Packing | Security Packing method with bubble foam and wooden case |
|
Webcam
|
Resolution | 1280*720 |
| Pixel | 8000000 | |
| Adaptive Resolution | 1280*720 | |
| Interface | USB 2.0 | |
| Driver | No | |
| Contactless IC / RF / NFC card reader | Status Display | LED indicator to show the power or communication status |
| Card Type | ISO14443TypeA of Contactless IC Card, including Mifare S50,Mifare S70,MF1ICL10,Mifare Pro,Mifare desfire,Mifare ultralight | |
| Type | Support ISO14443 | |
| Wireless module | WLAN module | With industrious antenna exposure |
| LED displaying | Function | Single or multiple colors letters displaying |
| Speakers | Features | Dual channel amplified speakers for Stereo ,8Ω 5W |
Other Optional hardware components List is as following:
Application
Our Advantages:
Desigh for higher standard and have a much longer life-cycle,has commecial-grade electronics
Help cut the lines,decrease less staff involvement
Display all preferences and items effectively,Increase sales opportunities and boosts the possibilities of repeat customers
Modular components that work together, but can be tested independently.
