Shenzhen Lean Kiosk Systems Co., Ltd.

LKS Indoor Kiosk Cash Deposit Machine Payment Terminal Android / Linux / JOS

Product Details:
Place of Origin: China
Brand Name: LKS or customized
Certification: CE, FCC
Model Number: LKS8327
Payment & Shipping Terms:
Minimum Order Quantity: 10 units
Packaging Details: Film Wrap,Foam and Wooden Box
Delivery Time: 4-6weeks upon payment
Payment Terms: T/T in Advance
Supply Ability: 1000-2000 units per month
  • Detail Information
  • Product Description

Detail Information

Kiosk Type:: Payment Kiosk Application:: Banking, Retail,Post, Transport, Library,
OS:: Window/Android/Linux/JOS Brightness: 650 Cd/㎡
Color:: Upon Clients Brand Name:: ODM/OEM
High Light:

cash payment kiosk


atm kiosk

Product Description


                        LKS indoor kiosk cash deposit machine payment terminal

Main components​​ ​​:

  1. Industrious PC
  2. 17 inch monitor
  3. 17 inch IR touch screen
  4. Printer
  5. Motorized card reader
  6. Barcode scanner
  7. Speaker
  8. Free standing single screen cabinet


Standard hardware components List of   LKS indoor kiosk cash deposit machine payment terminal

is as following:


Components Details
PC system Industrial Board Seavo/ Gigabyte/Advantech AIMB 562
CPU Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7
RAM 2GB /4 GB / 8GB
HDD 500G
Interface 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card
PC Power Supply HUNTKEY/Great Wall
LCD monitor Screen Size 32 inch ( optional from 8inch to 65inch)
Brightness 250cd/m2
angle horizontal 100°above;Vertical 80°above
Contrast 1000:1
Backlight tube life more than 40,000hours
Max. resolution 1280×1024
Touch screen Screen Size 32 inch Diagonal ( optional from 8inch to 65inch)
Resolution 4096x4096
High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times
Speaker Features
Accessories Wire-lan port, USB ports, speakers, fans, cables, screws, etc.
KIOSK Cabinet Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request.
Packing Security Packing method with bubble foam and wooden case



Other Optional hardware components List​​ is as following:


  1. Barcode scanner
  2. Contactless card reader
  3. Cash / Coin validator
  4. Coin dispenser
  5. Palm vein scanner
  6. Fingerprint scanner
  7. Wireless module like WLAN / GPRS / 3G / LTE
  8. Web camera
  9. ID scanner
  10. A4 Laser printer
  11. USB port
  12. Advertising screen


Main designs of LKS indoor kiosk cash deposit machine payment terminal:





Bank,School,ATM / VTM booth,Highway booth,Trade show,Conference room,Museum,HR room,Bank,Supermarket,Hotel,Hospital,Gas station,Shopping Mall,Theatre,Railway Station,Metro Station,Parking Lot,Fast food restaurant,Buss station,Other Public area



Our Advantages:


Designed for 24 / 7 operation

  • Highly responsive user interaction
  • Vandal resistant components
  • Tightly integrated hardwre and software
  • Industrious level for all hardware components

Cost-effective Solution

  • Stable-quality hardward components
  • Built on widely used stable provden technology
  • Complete supply chain management
  • Easy of Operation
  • Modular design for easy maintenance

Elegant Appearance

  • Attract end customers
  • Multi-color processed surface
  • Human engineering verification
  • Attractive decoration
  • High-quality design sketch
  • Regular elegant design

 Who choose us ?


 1.Professionalism in R&D and manufacturing. We are one of the very few factories in China


 2 which have the ability to both design and produce touch screen kiosks.


 3. Our annual production capacity is over 10000sets;


4 Perfect after sale service, fast response and repair service;


5. Have the most successful cases over almost every fields.
